Vehicle Specifications
Finding the right 3.5t van payload and dimensions is essential for staying legal and efficient on the UK’s roads. At Lincoln Commercial Bodies, we provide detailed technical data for our entire range of VCA-approved builds.
Renault Master MK4 Curtainside with Full Closure Taillift
Wheelbase
4225mm
Overall Length
6870mm
Internal Length
4225mm
External Width
2095mm
Internal Width
2095mm
Overall Height
3300mm
Internal Height
2205mm
Rear Aperture
2210mm
Vehicle & Body Weight
2540Kgs
Payload
960Kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master MK4 13'6"/4.1m Curtainside Barn with Doors
Wheelbase
4220mm
Overall Length
6680mm
Internal Length
4095mm
External Width
2090mm
Internal Width
2090mm
Overall Height
3325mm
Internal Height
2307mm
Rear Aperture
2164mm
Vehicle & Body Weight
2388Kgs
Payload
1112Kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master MK4 4.1m/13'6" Low floor Luton
Wheelbase
4230mm
Overall Length
6690mm
Internal Length
4100mm
External Width
2150mm
Internal Width
2105mm
Overall Height
3100mm
Internal height
2400mm
Rear Aperture
2240mm
Vehicle & Body Weight
2406Kgs
Payload
1094Kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master MK4 4.5m/14'9" Low floor Luton
Wheelbase
4230mm
Overall Length
7050mm
Internal Length
4495mm
External Width
2146mm
Internal Width
2105mm
Overall height
3100mm
Internal Height
2400mm
Rear Aperture
2240mm
Vehicle & Body weight
2462Kgs
Payload
1038Kgs
All weights & measurements have a tolerance of +/- 5%.
Renault master MK4 3.5Ton 14' dropside
Wheelbase
4220mm
Overall Length
6970mm
Internal Length
4260mm
External Width
2095mm
Internal Width
2025mm
Overall Height
2440mm
Vehicle & Body Weight
2080Kgs
Payload
1420Kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Tipper
Overall Length
5600mm
Internal Length
3200mm
External Width
2090mm
Internal Width
2030mm
Overall Height
3410mm
Vehicle & Body weight
2166kgs
Payload
1334kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton Luton with Tail lift (500kgs)
Wheelbase
4025mm
Overall Length
6770mm
Internal Length
4064mm
External Width
2091mm
Internal Width
2054mm
Overall Height
3155mm
Internal Height
2165mm
Rear Aperture
1857mm
Vehicle & Body weight
2472Kgs
Payload
1028Kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton 15'9"/4.8m Dropside
Wheelbase
4035mm
Overall Length
7280mm
Internal Length
4795mm
External Width
2085mm
Internal Width
2020mm
Overall Height
2410mm
Vehicle & Body weight
2144Kgs
Payload
1356Kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton 13'6"/4.1m Curtainsider with barn doors.
Wheelbase
4035mm
Overall Length
6580mm
Internal Length
4092mm
External Width
2090mm
Internal Width
2090mm
Overall Height
3310mm
Internal Height
2310mm
Rear Aperture
2160mm
Vehicle & Body weight
2392Kgs
Payload
1108Kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton 13'6"/4.1m Curtainsider with rear enclosure tail lift (500kgs)
Wheelbase
4035mm
Overall Length
6725mm
Internal Length
4100mm
External Width
2095mm
Internal Width
2095mm
Overall Height
3285mm
Internal Height
2300mm
Rear Aperture
2220mm
Vehicle & Body weight
2500Kgs
Payload
1000Kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton 13'6"/4.1m Curtainsider with roller shutter and tail lift (500kgs)
Wheelbase
4030mm
Overall Length
6770mm
Internal Length
4062mm
External Width
2089mm
Internal Width
2089mm
Overall Height
3304mm
Internal Height
2313mm
Rear Aperture
1985mm
Vehicle & Body weight
2510Kgs
Payload
990Kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay MK3 2025 Facelift 3.5Ton 14'9"/4.5m Low Floor Luton with barn doors.
Wheelbase
4035mm
Overall Length
6965mm
Internal Length
4495mm
External Width
2200mm
Internal Width
2160mm
Overall Height
3280mm
Internal Height
2495mm
Rear Aperture
2335mm
Vehicle & Body weight
2488Kgs
Payload
1012Kgs
Citroen Relay 3.5Ton Luton with Tail lift (500kgs)
Overall Length
6650mm
Internal Length
4050mm
External Width
2090mm
Internal Width
2050mm
Overall Height
3230mm
Internal Height
2120mm
Rear Aperture
1800mm
Vehicle & Body weight
2460kgs
Payload
1040kgs
Lightweight panels
2330kgs
Payload (Lightweight)
1170kgs
All weights & measurements have a tolerance of +/- 5%.
Peugeot Boxer 3.5Ton Low Floor Luton
Overall Length
6600mm
Internal Length
4100mm
External Width
2200mm
Internal Width
2150mm
Overall Height
3100mm
Internal Height
2520mm
Rear Aperture
2330mm
Vehicle & Body weight
2340kgs
Payload
1160kgs
Lightweight Panels
2210kgs
Payload (Lightweight)
1290kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay 3.5Ton 14’ Dropside
Overall Length
6750mm
Internal Length
4250mm
External Width
2090mm
Internal Width
2030mm
Overall Height
2400mm
Vehicle & Body weight
2024kgs
Payload
1476kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton 16’ Dropside
Overall Length
7350mm
Internal Length
4850mm
External Width
2090mm
Internal Width
2030mm
Overall Height
2400mm
Internal Height
N/A
Rear Aperture
N/A
Vehicle & Body weight
2090kgs
Payload
1410kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Curtainsider with Tail lift (500kgs)
Overall Length
6900mm
Internal Length
4060mm
External Width
2080mm
Inside Width
2080mm
Overall Height
3250mm
Internal Height
2300mm
Side Aperture Height
2200mm
Vehicle & Body weight
2464kgs
Payload
1036kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Luton with Tailift (500kgs)
Overall Length
6900mm
Internal Length
4060mm
External Width
2105mm
Internal Width
2030mm
Overall Height
3110mm
Internal Height
2140mm
Rear Aperture
1800mm
Vehicle & Body weight
2416kgs
Payload
1084kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Low Floor Luton with Barn Doors 13'.6"
Overall Length
6730mm
Internal Length
4100mm
External Width
2145mm
Internal Width
2070mm
Overall Height
3085mm
Internal Height
2400mm
Rear Aperture
2240mm
Vehicle & Body weight
2388kgs
Payload
1112kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Low Floor Luton with Barn Doors 14'9"
Overall Length
7130mm
Internal Length
4500mm
External Width
2145mm
Internal Width
2070mm
Overall Height
3085mm
Internal Height
2400mm
Rear Aperture
2240mm
Vehicle & Body weight
2415kgs
Payload
1085kgs
All weights & measurements have a tolerance of +/- 5%.
Citroen Relay 3.5Ton Curtainsider 13'6"
Overall Length
6700mm
Internal Length
4085mm
External Width
2083mm
Internal Width
2083mm
Overall Height
3290mm
Internal Height
2300mm
Side Aperture Height
2210mm
Vehicle & Body weight
2460kgs
Payload
1040kgs
All weights & measurements have a tolerance of +/- 5%.
Ford 3.5Ton Skeletal with Barn Doors & Step 16'4"
Overall Length
7500mm
Internal Length
5000mm
External Width
2250mm
Internal Width
2200mm
Overall Height
3050mm
Internal Height
2340mm
Rear Aperture
2170mm
Vehicle & Body weight
2344kgs
Payload
1156kgs
All weights & measurements have a tolerance of +/- 5%.
Iveco Daily 3.5Ton 13'6" Luton with Tail lift (500kgs)
Overall Length
7150mm
Internal Length
4460mm
External Width
2100mm
Internal Width
2060mm
Overall Height
3150mm
Internal Height
2125mm
Rear Aperture
1790mm
Vehicle & Body weight
2684kgs
Payload
816kgs
All weights & measurements have a tolerance of +/- 5%.
Iveco Daily 3.5Ton 15' Dropside
Overall Length
7100mm
Internal Length
4650mm
External Width
2100mm
Inside Width
2030mm
Overall Height
N/A
Internal Height
N/A
Rear Aperture
N/A
Vehicle & Body weight
2104kgs
Payload
1396kgs
All weights & measurements have a tolerance of +/- 5%.
Iveco Daily 3.5Ton 13'6" Curtainsider
Overall Length
6950mm
Inside Length
4500mm
External Width
2100mm
Inside Width
2100mm
Overall Height
3250mm
Internal Height
2125mm
Aperture Height
2200mm
All weights & measurements have a tolerance of +/- 5%.
Ford 3.5Ton Skeletal with Barn Doors & Step 14'8"
Overall length
7310mm
Inside Length
4500mm
External Width
2250mm
Inside Width
2205mm
Overall Height
3130mm
Internal Height
2330mm
Rear Aperture
2170mm
Vehicle & Body weight
2299kgs
Payload
1201kgs
All weights & measurements have a tolerance of +/- 5%.
Renault Master 3.5Ton Cage Tipper
Overall length
6000mm
Internal length
3255mm
Internal Width
2040mm
Overall Height
2810mm
Vehicle & Body weight
2515kg
Payload
985kgs
All weights & measurements have a tolerance of +/- 5%.
Ford Transit Traffic management 3.5t Tail lift (500kgs), Tow bar.
Overall Lenth
6820mm
Internal Length
4240mm
External Width
2240mm
Internal Width
2140mm
Overall Height
2370mm
Vehicle & Body weight
2466kgs
Payload
1034kgs
All weights & measurements have a tolerance of +/- 5%.
